KYM Series Washing Machines
| Model | Unit | KYM 2 | KYM 12 | KYM 30 | KYM 60 | KYM 100 | KYM 180 | KYM 230 |
|---|---|---|---|---|---|---|---|---|
| Capacity Enzme Washing | kg/cycle | 2 | 12 | 30 | 60 | 100 | 180 | 230 |
| Drum (Diameter x Length) | mm | Ø530×225 | Ø797×500 | Ø1000×730 | Ø1350×900 | Ø1500×1200 | Ø1820×1450 | Ø1820×1930 |
| Washing Speed | rpm | 0-40 | 0-40 | 0-40 | 0-40 | 0-40 | 0-40 | 0-40 |
| Motor Power | kw | 0,25 | 0,75 | 2 | 4 | 7,5 | 15 | 18,5 |
| Tilting Angle of Unloading | degree | – | – | – | – | 21 | 21 | 21 |
| Door Diameter | mm | Ø300 | Ø450 | Ø600 | Ø810 | Ø820 | Ø1000 | Ø1000 |
| Sample Door Dimension | mm | – | Ø162 | Ø230 | Ø290 | Ø290 | Ø390 | Ø390 |
| Water Consumption | lt/h | 8 | 35 | 105 | 200 | 350 | 600 | 900 |
| Steam Consumption | kg/h | 5 | 20 | 50 | 85 | 150 | 250 | 330 |
| Power Consumption | kw/h | 0,4 | 1,5 | 4 | 8 | 12 | 14 | 15 |
| Dimension (L x W x H) | cm | 67x82x50 | 94x96x145 | 136x130x179 | 190x169x225 | 210x200x230 | 235x264x255 | 235x333x255 |
| Weight | kg | 100 | 350 | 550 | 1200 | 2500 | 3500 | 4400 |
